Description
Topcon GR-5 Integrated
Topcon GR-5 Integrated includes the Universal Tracking Channel Technology-equipped multi-constellation 226-Channel Vanguard GNSS chip. Additionally, Topcon’s unique Fence Antenna Technology design, which offers a lightweight, portable antenna that spans the whole GNSS frequency range for unparalleled performance, is included in the GR-5. With the most advanced acquisition algorithms from Topcon, Fence Antenna, and Vanguard, the GR-5 receiver provides the most reliable GNSS tracking performance on the market.
The combination of a compact form factor, revolutionary Universal tracking technology, and multiple communication methods makes the Topcon GR-5 receiver the most popular and versatile option for high precision GNSS reliability.
Capable of tracking GPS, GLONASS, BeiDou, Galileo, QZSS constellations
Universal Tracking Channels capable of all-in-view tracking
Track every satellite constellation above today and tomorrow
Signal scrubbing Fence Antenna® to provide ultimate signal lock
Highest accuracy positioning for RTK, network, and more
Offers choice of UHF or Spread Spectrum radios, as well as an optional, internal cellular modem for all your project needs
Topcon GR-5 Integrated GNSS Receiver Specifications
GNSS Tracking
Signals Tracked : GPS, GLONASS, Galileo*, BeiDou*, SBAS, and QZSS
Number of Channels: 226-Channel Vanguard Technology™ with Universal Tracking Channels
Accuracy
Static/Fast Static: H: 3.0 mm + 0.4 ppm, V: 5.0 mm + 0.5 ppm
Precision Static: H: 3.0 mm + 0.1 ppm, V: 3.5 mm + 0.4 ppm
RTK (L1+L2): H: 5 mm + 0.5 ppm, V: 10 mm + 0.8 ppm
Communications
Base radio output: 1.0W
Cellular: Integrated HSPA+/CDMA
I/O Communications: Class 2 Bluetooth, USB and Serial
Data
Memory: Removable SD/SDHC Card
Real Time Data Output: TPS, RTCM SC104 v2.x, 3.x and MSM, CMR/CMR+
ASCII output: NMEA 0183 version 2.x, 3.x and 4.x
Physical and Environmental
Enclosure: Magnesium I-Beam Housing
Operating Temperature: -30ºC to 70°C, -30ºC to +60°C with integrated batteries.
Certifications and Standards
Shock Rating: 2 m pole drop to concrete, IEC 60068-2-29, IEC 60068-2-27
Vibration Rating: Compliance with MIL-STD 810F – 514.5-Cat.24
